2.injector test. stimulate engine runing condition, test injector in different speed range,
Check and test injectors’s injection situation: atomization/spraying angle/spraying
amount/spraying uniformity;
3.leakage and block test;
4.Uniquely designed various compound bonder for different kinds of injectors;
5.With reverse flush function, to clean inside out, to improve clean efficiency;
6.With a set of adaptors to clean injectors without dismantling it from the engin.
Features:
1. LED display;
2. Ultrasonic cleaning trough built-in;
3. Tool trolley make it more conveniently to operate;
4. Equip with high quality SIEMENS pump, make it endurable.
Specification:
| Turning speed range: | 0~7500r/min |
| Timing pulse length: | 0~9900times/step length 100 |
| Pulse length: | 0-20ms step length 0.1ms |
| Timing: | 0~10min |
| System pressure: | 0~0.6Mpa |
| Ultrasonic cleaning power: | 70W |
| Power supply: | AC220+-10% 50/60Hz |
| Working temperature: | 10°C~40°C |
| Stimulant signals: | 0+-5V |
| Output scope of the pulsed signals: | +5V,+12V |
Details:
1. Imported fuel pump.
2. Aluminum Washer.
3. LED backlight.
4. Durable Adapter.
5. Inspection.
6. Optional Adapter.
7. Package.
